Industrial-grade lashing chain for cargo securing, towing, and general purposes. Hot-dip galvanized finish with min. average coating thickness of 80 μm.
Standard: DIN763
Link type: Long link (L/D > 3.5)
Material traceability: Yes – mill test certificate available
Applications: Marine, industrial, agriculture, construction, ports
Why SMEOCEAN: Direct manufacturer | In-house galvanizing | Mill test certificate available | Full traceability
Safety note: For lashing only – not for overhead lifting.
Hot Dip Galvanizing Long Link Chian Diagram:

Specification of Hot Dip Galvanizing Long Link Chian:
| Nominal specification, breaking load, tension load and unit weight Unit KN |
| A(mm) | B(mm) | C(mm) | WILL(Kg) | Proof Load(KN) | Weight per M(Kg) |
| 8 | 52 | 32 | 400 | 8 | 1.1 |
| 9 | 59 | 36 | 530 | 10.5 | 1.41 |
| 10 | 65 | 40 | 630 | 12.5 | 1.75 |
| 11 | 72 | 44
| 790 | 15.8 | 2.11 |
| 12 | 78 | 48 | 940 | 18.8 | 2.55 |
| 13 | 82 | 52 | 1000 | 21.2 | 2.95 |
| 16 | 100 | 64 | 1600 | 33 | 4.45 |
| 18 | 113 | 70 | 2120 | 42.3 | 5.65 |
| 19 | 119 | 72 | 2370 | 47.3 | 6.25 |
| 20 | 120 | 75 | 2500 | 50 | 7 |
| 22 | 127 | 82 | 3170 | 63.3 | 8.55 |
| 25 | 140 | 88 | 4090 | 81.7 | 10.9 |
| 28 | 152 | 96 | 6000 | 120 | 13.9 |
| 32 | 171 | 118 | 8000 | 160 | 18.2 |
